Metal Shop Action Plan

Metal Shop Evolving vision strategic Plan
Introductory statement:
This plan has been developed for the purpose of bringing the metal shop up to a high standard of cleanliness, accessibility with good working condition machines.
This plan also incorporates short and long term goals, objectives, needs and resources that are intended to take HSBNE into the future.
Authors of the plan:
Craig Rea (current Metal Shop Leader)

Organizational Structure:
The metal shop has come a long way since its establishment through many changes, improvements and upgrades, trying to establish a foundational structure with the right machines and tooling that works for the needs and desires of the members of HSBNE.
We believe that we are on the right track to achieving this goal and it’s through this plan that the improvements will continue.
Vision:
A comprehensive work shop that is clean and convenient for members to get access to working machines and tooling.

Values:
To always maintain a clean and tidy work space/environment with a high standard of safety and a respect for other members of HSBNE using the metal shop.
Mission Statement:
To make available to members of HSBNE large and expensive machines that they would normally not be able to own because of limited space and 3 phase electricity.

Infrastructure
The metal shop will be undergoing an infrastructure change, consisting of electrical upgrades, walls and floor painted and machines, benches and cabinets repositioned.
Time line for this to be complete is dependent on a few factors like a new lease agreement, landlord approval and funds.
Proposed time for completion end of march 2021

Machines and their associated tooling found in the metal shop at HSBNE.

Industrial # 3 Morse Taper Geared Head Drilling Machine (Hafco-GHD-22) 3 Phase
• Machine Status: This Drill Press is in good working order with a new replacement cost of $2,805
• Induction: This machine will require a 15 minute induction and has a swipe card access.
• Consumables: This drill press essentially does not use consumables. Metal shop does have drill sets and loose drills around the work shop, but generally it is up to the members to bring their own drill bits.

Features:
• Ideal for industrial or workshop use
• Geared head drilling machine with 3 morse taper spindle
• 8 drilling speeds from 105 - 2900 rpm
• High/low with forward & reverse switch
• Helical cut gears for quiet & smooth operation
• Swivel safety drilling chuck guard
• Rack and pinion wind-up drill head
• Rack & pinion table height adjustment with locking lever
• Thick walled column ensuring greater rigidity
• Drill ejector lever
• Safety emergency stop/reset switch
• Table rotates 360º
• Drilling depth stop setting with scale
• T slotted work table
Includes:
• 16mm keyed drill chuck and arbour
• Chuck key to suit
• Drill drift tool to remove drill chuck or taper shank drill.

Associated Tooling for the Drill Press:
Drill Press Vice (HF-140)-this item is in good working order with a new replacment cost of $220 inc. gst.

140mm Jaw Width
140mm Jaw Opening
Features:
• Hardened Prismatic Jaws

Clamp Kit 58 piece (HF-14) - Workshop Series- this Kit has a few pieces missing. New replacement cost is $110 in. gst.

Suits 14mm Table Slot
M12 x 1.75mm Stud
Features:
• 58 piece clamp kit
• Black oxide finish, tool steel, heat treated
• Rolled threads
Includes:
• 6 x T-Slot nuts
• 6 x Flange nuts
• 4 x Coupling nuts
• 6 x Step clamps
• 12 x Step blocks
• 24 x Studs (4 each = 75mm, 100mm, 125mm, 150mm, 175mm, 200mm length)
• 1 x Storage unit

Accessories and tooling to be purchased/fabricated for this machine by the end of February 2021

Aluminium Magnetic Soft Jaws-(V0539) This item is in good working order with a new replacement cost of $19.80 inc. gst. To be purchased by end of January 2021.

Aluminium Prism Face
150mm
Features:
• Easy to use. Simply place over existing jaws
• Protects work piece from scoring or marking
• 2 Magnetic tabs holds jaws in place
• Supplied as a pair

Plastic Magnetic Soft Jaws-(V0546) This item is in good working order with a new replacement cost of $19.80 inc. gst. To be purchased by end of January 2021.
Multigrip
150mm
Features:
• Multigrip allows of holding round horizontal or vertical
• Easy to use. Simply place over existing jaws
• Protects work piece from scoring or marking
• Magnetic strip holds jaws in place
• Supplied as a pair

C0832 - U-Clamp-(C0832)This item is in good working order with a new replacement coast of $93.50 inc. gst. To be purchased by end of January 2021.

M12 Stud, Suits 14mm Table Slot
Set of 2
Features:
• Material S45C
• Easy adjustment
• Sold in pairs
• With brass pads to protect work pieces from damaging

Wall unit with a shelf and draw with peg board backing. This unit will be the home for the accessories for the drill press.
Sample below: purchase or make by end of February 2021.

Vertical Milling Machine (Pacific FTV-2S) 3 Phase
With a variable speed head; 45-3500rpm, Table= 1270mm x 255mm, It has a 2.2kw motor and a 3 axis Digital Read out (DRO).
• Machine Status: This Vertical Mill is in good working order with a used replacement cost of $8,000. It has just recently undergone some improvements and repairs. All that is required is to replace the 2 handles on the ‘x’ axis table and coolant added. To be completed before Christmas 2020.
• Induction: This machine will require a 40 minute induction and has a swipe card access.
• Consumables: This Vertical mill essentially does not use consumables except coolant. Metal shop does have loose milling cutters around the work shop, but generally it is up to the members to bring their own milling bits.

Associated Tooling for the Milling Machine:
Cabinet: This Mill has an accompanying cabinet that houses the tooling for the mill.

Collet & Chuck Set – (NT40 x ER40) 25 Piece
Collet Range Ø3 - Ø26mm
“Made in Taiwan”
Overview:
Precision NT40 collet chuck with a ball bearing nut and a full set of ER40 collets.

Features:
• Includes spanner
• Chuck and collets as listed
• In blow mould case

Milling Vice (brand ?)
203mm Jaw Width
146mm Jaw Opening
Features:
• Jaws hardened and ground alloy steel
• All working surfaces, such as top and bottom of bed, jaw plates and base, are precision ground square and parallel
• Bearing portion of the acme-threaded leadscrew is ground for accurate alignment
• Graduated swivel base with large, easy-to-read divisions

Clamp Kit 58 piece – (HF-16)
Suits 16mm Table Slot
M12 x 1.75mm Stud
Features:
• 58 piece clamp kit
• Black oxide finish, tool steel, heat treated
• Rolled threads
Includes:
• 6 x T-Slot nuts
• 6 x Flange nuts
• 4 x Coupling nuts
• 6 x Step clamps
• 12 x Step blocks
• 24 x Studs (4 each = 75mm, 100mm, 125mm, 150mm, 175mm, 200mm length)
• 1 x Storage unit

Measuring Kit - 4 Piece (M012)
Includes:
• 0 - 25mm Micrometer
• 150mm / 6" Rule
• 150mm / 6" Vernier
• 100 x 70mm Square

Parallel Set - 18 Piece (M252) this item is in good working order and is a complete set, it has a replacement cost of $217.80 inc.gst.

Features:
• Length (L) & Height (H) tolerance to 0.005mm
• 150mm long
Includes:
• W x H x L (mm)
• 2 x (8.5 x 14 x 150mm)
• 2 x (8.5 x 16 x 150mm)
• 2 x (8.5 x 20 x 150mm)
• 2 x (8.5 x 24 x 150mm)
• 2 x (8.5 x 30 x 150mm)
• 2 x (8.5 x 32 x 150mm)
• 2 x (8.5 x 36 x 150mm)
• 2 x (8.5 x 40 x 150mm)
• 2 x (8.5 x 44 x 150mm)

Collet Block Set: ER 40-Hexigon and Square
These items are in good working order and hae a replacment cost of $110

1-2-3 Blocks 40mm x 20mm x 10mm

V Blocks 2off 60mm x 50mm x50mm

Center Drill Set: High Speed Steel-5 piece set-sizes 1-5

Milling Machine cnc (TopTech M4) Single Pase
Description:
This machine is 240v power single phase with a NT40 Spindle. A 18mm Tee table. X travel 500mm y travel 240mm z travel 500mm.

Runs Siemens CNC Control Panel Include all manuals and instructions . Can be connected to Computer to upload and download programs. Is a good machine to start getting into CNC machining.

• Machine Status: This Milling Machine is in good working order with a new replacement cost of $?
• Induction: This machine is not user friendly (crashes easily) it requires high level knowledge to operate it. The use of the mill has to go through Dave Seff (1st Advisor to the metal shop.)
• Consumables: This mill uses coolant. Cutters to be supplied by the member.

Milling Machine (Aciera F3) 3 Phase
This machines is in good working condition with a replacment cost of about $15,000. It will require an interloack and cabinate to store the accessiores. It will require an induction to operate this mill.
Description:
Range:
Longitudinal : 300 mm
Transversal : 135 mm
Vertical : 300 mm
Spindle : W20
Spindle speed : 100-2’000 rpm
Feed rate : 12-232 mm/min
Power supply : 3x380V/50Hz
Dimensions : 1500 x 1200 x 1000 mm
Weight : about 500 Kg
• Machine Status: This Mill is in good working order with a new replacement cost of $15,000. It just needs a position to place it in with power available.
• Induction: This machine will require a 40 minute induction and will require swipe card access.
• Consumables: This mill essentially does not use consumables except coolant. Metal shop does have loose milling cutters around the work shop; generally it is up to the members to bring their own milling bits.

Metal Lathe (Acraturn Blue) Single Phase
Cabinet: This Lathe has an accompanying cabinet that houses the tooling for the mill.

• Machine Status: This Lathe is in good working order with a used replacement cost of $2,000.
• Induction: This machine will require a 40 minute induction and has a swipe card access.
• Consumables: This Lathe essentially does not use consumables except coolant. Metal shop does supply some cutting tips, generally it is up to the members to bring their own turning tips.

Accessories for this lathe:
• 3 Jaw chuck with reverse jaws.
• 4 Jaw chuck
• Quick change tool post with 4 tool holders.
Tooling for this lathe:
• Drill chuck.
• Live centre
• Turning tool.
• Boring bar.

Metal Lathe (Acraturn Green-GH1440A) 3 Phase
Cabinet: This Lathe has an accompanying cabinet that houses the tooling for the mill.

• Machine Status: This Lathe is in good working order with a used replacement cost of $5,000.
However it requires the following: 1. new face plate mounting holes to be taped out to m4 and 12 x m4 dome head alan key bolts purchased s/s. 2. Levelling feet to be installed and lathe levelled. 3. Check run out on head stock and tail stock. 4. Oil change for the apron. 5. Carriage is jerky in 2 to 3 spots in the rack. 6. Cross slide needs a new scale. 7. Coolant hose has a small leak at the pump end. 8. Change gears 40-50-50-45 to be purchased. 9. New quick change tool post 20mm purchased and installed. 10. Some basic tooling, turning tool and boring bars, purchased. 11. Digital read out (DRO) purchased and installed.
These repairs and improvements to be completed by the end of March 2021.
• Induction: This machine will require a 40 minute induction and will require swipe card access.
• Consumables: This lathe essentially does not use consumables except coolant. Metal shop does supply some cutting tips; generally it is up to the members to bring their own turning bits.

Accessories for this lathe:
• 3 Jaw chuck with reverse able jaws.
• 4 Jaw chuck.
• Steady.
• Travelling Steady.
• Live centre.
.
Cabinet &Tooling for this lathe:
• Drill chuck.
• Turning tool.
• Keyless chuck.
• De-burring set.
• Morse taper sleeve from MT 2- MT3
• Metric drill set.
• Boring bar.

Metal Cutting Band Saw - Swivel vice (BS-7DS) Single Phase

• Machine Status: This Band saw is in good working order with a new replacement cost of $1,529.
The interlock swipe box needs mounting to the machine.
To be completed by the end of January 2021
• Induction: This machine will require a 5 minute induction and has a swipe card installed.
• Consumables: This Band saw uses approximately one cutting blade per month and approximately 10 litters of mixed coolant per month due to evaporation. Metal shop does supply the blade and coolant.

Overview:
Manufactured in Taiwan

The BS-912 is a larger 240 volt band saw suitable for the medium fabrication and general engineering workshops. It features increased motor power, four blade speeds, double row ball bearing blade guides, a built-in coolant system and greatly increased cutting capacity.

The downward cutting pressure is controlled by a fully adjustable hydraulic damper with an on/off valve and there is an automatic cut-off at the end of the cut. The vice rotates for mitre cutting and there is an adjustable material stop for consistent repeat length cutting.

Features
• 305 x 178mm (W x H) rectangular capacity
• Adjustable hydraulic feed cutting rate for multiple applications
• Mitre cuts to 45º using calibrated vice
• Built-in coolant system to both blade guides for maximum cutting efficiency
• Limit switch stops machine when cut is complete
• Quick action material clamping lever
• Adjustable blade roller guides provides accurate cutting
• Adjustable 4-speed pulley drive system enabling 26-50-73-95mpm cutting speeds
• Adjustable length stop for repetition cutting
• Wire wheel brush to clean swarf from blade
• Portable - on wheels for ease of use
• Automatic electric cut-out switch
• Heavy-duty 750W 240V fully enclosed fan-cooled motor

Band Saw (Start-Rite Volant 18) 3 Phase
• Machine Status: This Band saw is in good working order with a used replacement cost of $1,000. This band saw will require levelling feet as seen in the pitcher.
To be completed by end of February 2021.
• Induction: This machine will require a 15 minute induction and will require a swipe card installed.
• Consumables: This Band saw uses approximately one cutting blade per month. Metal shop does supply the blades.
Description:
Metalworking Band Saw - with Cast Iron Table, Blade welding attachment, 4 speed Belt Drive, 415 volt Plug-in.

Omes Cold Saw (MEC 300s) 3 Phase
• Machine Status: This Cold saw is in good working order with a used replacement cost of $500. This cold saw needs positioning and power supplied.
To be completed by end of march 2021.
• Induction: This machine will require a 10 minute induction and will require a swipe card installed.
• Consumables: This Band saw uses approximately two cutting blades per month and approximately 5 litters of coolant per month due to evaporation. Metal shop does supply the blades and coolant.

Repco- Universal grinder: 3 Phase
3 Phase
• Machine Status: This Grinder is in good working order with a used replacement cost of $1,500.
• Essential tasks:

  1. Machine arbour for surface grinding (due Dec 13)
  2. Fabricate wheel guard for surface grinding (due Dec 31)
  3. Create mounting plate for cylindrical grinding attachment (due Jan 17)
  4. Make guards to control grinding dust (due Feb 28)
  5. Perform risk management analysis (due Mar 14)
  6. Create manual induction procedure (due Mar 31)
    • Further improvements:
  7. Get coolant system working
  8. Look into dust extraction options
  9. Manufacture tool grinding attachments
    • Budget:
  • Arbour materials: already purchased from initial funding
  • Steel plate for cylindrical grinder attachment: already purchased from initial funding
  • Sheet metal for guards: $150 (2x 1.15mm full sheets from early bird steel)
  • Paint for guards: $50
    • Induction: This machine will require a 40 minute induction and will require a swipe card installed.
    • Consumables: This Grinder uses a variety of cutting stones which are changed out depending on your job. Grinding stones may only need replacing once a year. Metal shop does supply the stones and coolant. The Grinder uses approximately 5 litres of coolant per month due to evaporation.
    Description:
    • Model: TCIA
    • 3 Phase
    • 1000mm (l) Bed
    • 1600mm x 1200mm x 1250mm (h) Approximately

Renegade Industrial 20 Tonne 20000Kg Hydraulic Shop Press (Renegade)
• Machine Status: This Press is in good working order with a used replacement cost of $289.
• Induction: This machine will require a 10 minute induction.
• Consumables: This press essentially has no consumables.

Key Features:
• Maximum Load Capacity: 20,000KG / 20 Ton
• Working Range: 0-710mm
• Stroke Length: 150mm

LINISHALL 200MM (8") HEAVY DUTY BENCH GRINDER 1HP 750W # BG8-SINGLE PHASE
• Machine Status: This Linisher is in good working order with a used replacement cost of $600.
• Induction: This machine will require a 5 minute induction.
• Consumables: This Linisher uses approximately six belts per month.
The perfect fit in any workshop. With a 750 Watt motor, adjustable work light, cast metal tool rests, emergency stop safety switch and unique adjustable magnified eye shields.
Features:
• 200mm (8") Wheel Size
• Thread M16 x 2
• 2850 RPM
• Wheel Bore Size 16mm
• 750 Watt Motor
• Safety Emergency Switch
• Adjustable Oval Eye Shields With Magnifying Glass
• Cast Metal Tool Rests
• Adjustable Work light
• Includes 2 x Grinding Wheels
• Weight: 26kg

Radius Master Bench Belt Grinder / Linisher (RM-48B)

• Machine Status: This Linisher is in good working order with a new replacement cost of $2,288.
• Induction: This machine will require a 10 minute induction.
• Consumables: This Linisher uses approximately six belts per month.

Description:
50 x 1220mm Belt Size
7 Work Stations
Overview:
The Best Knife Making Machines & Belt Grinding Machines In The World
Radius Master’s unique design provides a multitude of functions via 7 work stations, each readily available in seconds and without tools, using an easy to operate index knob. Only the Radius Master brand of machines are capable of tracking the latest heavy duty polyester backed ceramic belts. 7 work stations provide a wide variety of surface finishing, intricate product de-burring, tube notching, profiling and precision sharpening of drills and cutters.

Radius Master provides accurate tracking performance, allowing notching into sharp corners for better product finishing and significant savings on consumables, such as belts and contact wheels.

Lightning fast belt changes, 7 work stations and 5 contact wheels result in savings of hours per day on many jobbing, restoration and prototype work.

Designed for engineers, fabricators, welders, fitters, balustrade and stainless specialists, foundries, toolmakers, knife makers, rural manufacturers, mechanics, restorers, aircraft engineers, medical equipment manufacturers, sculptors, model makers and manufacturers of many wood and plastic products.

The Radius Master multi station belt grinder can do it all!
Features
• 7 work stations, 5 contact wheels (Ø25-Ø200mm), side tilt for pipe notching - all instantly accessible
• Uses include contouring, squaring, facing, de-burring (inside tube included), sharpening, all stainless finishes, texturing, micro finishing and polishing
• Outstanding tracking allows notching sharp corners at the very edge of the belt. 3 x Plus better belt life
• Dust proof switch and 10ft (3m) lead and plug provided
• Can be laid on its side for profiling pipe notching etc. Table tilts to 45º
• The only belt grinder that accurately and rigidly tracks the heaviest backed belts (essential in drill & cutter sharpening)
• Sealed bearings Teflon gaskets - adjustable pivots give many years life expectancy - Designed from 35 years’ experience in belt grinding
• Internal, external and hollow grinding on 5 contact wheels
• Flat grinding in vertical and horizontal position
• Edge grinding on tool rest (tilts up 20° and down 45°)
• Slack belt grinding in horizontal and vertical positions
• Its accurate tracking is an unmatched asset in precision sharpening of small drills & cutters and allows the use of cut down belts to 8mm for finishing & de-burring difficult contours.
• Tracking mechanism will never lose its precision as vital pivots are sealed ball bearings
• De-burring of tube inside and outside
• Performance and durability backed by a 2 year commercial warranty
• Unmatched accuracy, versatility, performance & durability
• 50 x1220mm belt (6 sec belt change)
• 240V 1.5kW MOTOR totally enclosed with overload protection
• 20 year life expectancy
• Made in Australia
Includes
• Tool rest
• Notching tilt table
• 1 x zirconia belt
• 5 contact wheels (Ø25-200mm)
Optional Accessories
• Platen Table (L097)

Plasma Cutter (UNI-PLAS 50/80) 3 Phase

• Machine Status: This Plasma cutter is in good working order with a new replacement cost of $1929.
• Induction: This cutter will require a 15 minute induction.
• Consumables: This cutter essentially uses electricity and compressed air.

20mm Steel Capacity- 3phase.

Overview:
The Uni-Plas 50/80 is a conventional high duty cycle plasma cutting machine This machine is reliable, robust and stacked with features that you expect from a quality plasma cutter. Features include switching from Manual trigger switching to Automatic trigger switching to allow use with straight neck machine cutting torches.

The Uni-Plas 50/80 produces a high temperature plasma stream, enabling effortless cutting of all electrically conductive materials including steel, cast iron, stainless steel, copper, aluminium brass etc .

The Uni-Plas 50/80 is equipped with a high quality Italian manufactured Tecmo T100 Plasma Torch developed specifically to enhance and improve the cut quality of the Uni-Plas 50/80 machine. Connection of the Tecmo T100 Plasma torch provides powerful, fast and accurate cutting performance; additional benefit is the longer life cycle of the consumable electrodes and cutting tips. The high frequency ignition ensures effortless and clean cut starts for standoff cutting, contact cutting is possible by installing the contact cutting torch parts. The Uni-Plas 50/80 is an exceptional machine that is suitable for a wide range of applications including general engineering, fabrication, agricultural, repair and maintenance services.

The Uni-Plas 50/80 is packaged with a 6 metre Tecmo T100 Plasma Torch, earth lead and air regulator. The Uni-Plas 50/80 gives you the power and performance to get the job done.

CUTS:

  • STEEL
  • ALUMINIUM
  • STAINLESS
  • COPPER
  • BRASS

Features:
• Ideal for general workshop use
• Dual amperage setting
• Fan-cooled copper-wound transformer
• Thermal overload protection
• Quality torch supplied with unit
• 415V

Specifications:
ORDER CODE C480
MODEL UNI-PLAS 50/80
Part Number KUP50/80
(mm)Cutting Capacity - Steel 20
(mm)Cutting Capacity - Aluminium 16
(amp)Recommended Plug 32
Duty Cycle 40% @ 80 amp
(amp)Current Range 50-80
(PSI)Air Pressure Required 80
(L/min /Bar)Air Flow Capacity Required 230 / ~
(V / amp)Voltage / Amperage 415 /
(mm)Dimensions 710 x 720 x 540
(kg)Nett Weight 155

Mig Welder (CIG Transmig) With large radial arm. 3 Phase
• Machine Status: This Welder is in good working order with a used replacement cost of $? However it needs a new gas line (leaking)
• Induction: This machine will require a 15 minute induction.
• Consumables: This Welder uses 0.9 Mig wire on a 15kg spool and Argon/shield gas.

Mig Welder 425SWF -Uni Mig KT 50 40-400 Amps
• Machine Status: This Welder is in good working order with a new replacement cost of $5,000 3 phase
• Induction: This machine will require a 15 minute induction.
• Consumables: This Welder uses 0.9 Mig wire on a 15kg spool and Argon/shield gas.

Overview:
The UNIMIG 425 SWF is a powerful workhorse with an exceptionally high duty cycle. It is ideally suited for medium to heavy fabrication industries as well as rural applications. Combining smooth arc characteristics with complete reliability, the UNIMIG 425 SWF is the unit to satisfy all the demands of the professional welder.

The UNIMIG 425 SWF features a completely enclosed KT 50 wire feed unit which helps prevent dust and moisture fouling your wire and contaminating your weld. Fitted standard with a geared four wheel roller drive system ensuring consistent wire feed and smooth welding. It comes with a set of fully covered 10 metre interconnecting cables and wheels for increased manoeuvrability.

High Duty Cycle operation 50% at 400 Amps
30 Voltage positions
Triple inductance settings for optimum arc characteristics on thin or thick material
2T-4T trigger operation (MIG Only)
Stich and Spot welding modes
Adjustable Burn back control

Features:
• Four wheel geared wire drive system
• Separate Wire Feeder
• 10 metre inter connecting cables
• Triple Inductance for exceptional arc control
• High strength steel construction
• Heavy duty copper wound transformer
• Exceptional high duty cycle 50% @ 400 amps
• European made quality manufactured in Hungary
• Robust cabinets with steel/rubber wheels
• SWF models come with wheels and a swivel platform for wire feed unit
• SWF accommodates 15kg wire spools
• Thermal overload protection ensures efficiency

Includes:
• KT 50 Separate Wire Feeder complete with 10 metre interconnecting cables
• SB36 4M Ergo MIG torch with Euro connection
• 10M Earth lead with 35/50 Dinse style connections
• UNI-FLAME Twin Gauge Argon Regulator
• Gas Hose with Fittings

Specifications:
ORDER CODE W253A
MODEL Workshop 425 SWF
Type MIG
Part Number KUM425SWF
(V)Voltage 415
(amp)Recommended Plug Amperage 32
(amp)Welding Current Range MIG 40 - 400
(% @ amp)Duty Cycle 50 @ 400
(kg)Wire Spool Size 5 & 15
(mm)Ferrous Wire Size - Range 0.6 - 1.6
(mm)Stainless Steel Wire Size - Range 0.6 - 1.6
(mm)Aluminium Wire Size - Range 0.9 - 1.6
(mm)Dimensions 1270 x 940 x 600
(kg)Nett Weight 182

Weldmaster Tig 200p VRD-Single Phase 15 amp
• Machine Status: This Welder is in good working order with a used replacement cost of $1000. Single phase 15 amp.
• Induction: This machine will require a 15 minute induction. A interlock swipe card is required to be installed.
• Consumables: This Welder uses electricity and Argon gas to operate it. Tungsten electrode and filler rods required, supplied by individual members.

Description
Weld master i-TIG 200P AC/DC Pulse Inverter VRD Welder, 200 Amp. 240 Volt, single Phase. Pulse Inverter Welder.

Oxy & Acetylene Set.
• Machine Status: This set is in good working order with a used replacement cost of $? A decent trolley is to be made up and painted yellow for visibility, as per the pitcher.
To be completed by March 2021.
• Induction: This gas set will require a 10 minute induction.
• Consumables: This gas set uses oxygen and acetylene approximately every six months.

G-Clamps:
Status: Good working order.

Tool boxes Status with hand tools.
• The tools in this tool box need to be organized into there catagories and labeled. To be completed by end of february 2021.

Tool Box Status:
This tool box is in good working order, how ever there are hand tools missing, a hunt around in the other tool box and work shop may find the missing tools.
To be completed by end of Janruary 2021.

Angle Grinders
• Status: 2 x 5 inch Milwaukee grinders in good working order with a new replacment cost of $150 each
• Induction: Go to below link for the safe use of angle grinders.


• Consumables: It is essentially up to the individual members to supply there own cutting and sanding discs.

FEATURES:
• Powerful 800W motor for maximum durability and performance
• Compact and slim design for comfortable use
• Burst resistant safety guard for best user protection
• Two-position handle for increased end user comfort

Height gage and marking out table:
• Machine Status: This Height Gage is in good working order with a new replacement cost of $350.
• Induction: This Height gage will require a 5 minute induction.
• Consumables: This Height Gage essentially has no consumables.

Benches & Cabinets:
• A new solid bench to be fabricated with lighting , storage and a solid vice to be completed by end of may 2021.
• Cabinate for angle grinders, clamps welding accessories ect. The cabinet has been aquired just needs the base painted and installed and the items stacked in with labelling. To be completed by end of january 2021.

Cordless Battery Drills skin only:
• Status: 2 x cordelss Ryobi drills in good working order with a new replacment cost of $99 each
• Induction: Go to below link for the safe use of angle grinders.


• Consumables: It is essentially up to the individual members to supply there own drill and driver bits. Howerver there are some loose drill bits in the red tool box.

• 13mm keyless chuck for tool-free bit changes
• 2 speeds and 24 clutch settings to prevent over tightening
• LED work light at the foot of the tool for improved illumination
• Drilling Diameter on Wood: 38mm, Drilling Diameter on Steel: 13mm
• Max Torque: 50Nm
The RYOBI 18V ONE+ Drill Driver is one of the best DIY tools you can own because it’s two tools in one – a powerful screwdriver and a drill. The 13mm keyless chuck accepts all standard-sized bits. Choose between 2 driving and drilling speeds. And with the 24 clutch settings in the driving mode, you’ll always deliver the right amount of power and torque to drive fasteners without over-tightening and damaging the materials you are working on. Simply add any ONE+ Battery to the Drill Driver to get started on your next project. The RYOBI 18V ONE+ Drill Driver is a great all-rounder and will be a real asset to your toolbox.

Wall Unit for Ryobi cordless drills:
Status: New purchase buy the end of Februuay 2021.
$79 from bunnings
• All steel construction for extra durability
• 4 holders for power tools
• Easy attachment to walls
• Peg holes, and pull through power access holes for ultimate versatility
Keep your workshop organised and convenient with the RYOBI Hanging Wall Storage - Open Shelf. This solid steel unit has been constructed to hang 4 ONE+ tools beneath, with countless storing options in the shelves above. The power access holes allow you to charge batteries or equipment from the unit. And for added hanging options, each side panel is fitted with peg holes. Fitting the unit is just as convenient, with screw holes pre-drilled in the unit. The RYOBI Hanging Wall Storage - Open Shelf makes the ultimate tool range even easier to use and manage.

*Please note - Maximum weight capacity 125kg, please refer to manual for recommended weight distribution.

Floor Plan: To be added.

1 Like

I’ll admit, I’ve only skimmed through the tool details, but what an astounding amount of detail and planning! Tagging @GeoffC, as he’s offered to work on the Wiki and a lot of the info is here!

Craig, I want to sincerely congratulate you on the thoroughness and extent n of your document. Outstanding work!! I hope this sets a precedent for the exactness and profesionalism of other causes work!!

thanks Emily and Zack, there is still some areas that need addressing but a good start. Geoff has offered to help with the documenting of the machines and tooling onto wiki, which I am very grateful and helps us all to get the space up to a high standard.
I would like to put it out to metal shop members first and then the rest of the members for there help in achieving the tasks that have been listed in the plan by there allotted time. my goal is to give out assignments of the various task to the suited member to complete.
If nobody objects to this initiative then I will move forward with the assignments. thank you in advance for all your help. Craig

Excellent work @reatek66! That is certainly a thorough plan! :smiley:

Like it says above. I am working on the Wiki part. If you want to help build the wiki there is plenty of opportunity. Our most excellent and fearless cause leader has given us a solid foundation and big head start. Note Metalworking has a LOT OF TOOLS.

Members can help by understanding that the wiki will be built from the top down, first publishing all Cause tools, then into the details for each tool page. My approach is to first publish all the tools but with an ‘empty’ page. Then go back and complete each tool page.

Members are asked to

  • Photograph groups of hand tools and tool chests that look like they would go the tool page.

  • Complete each tool page with the info in the Cause Plan. It may seem odd but I’m looking at sending you two text documents from the Wiki page editor. One is a completed page, the other is for you to ‘fill in’ based on the completed page. That way you do not need to be online or concerned about mistakes. I’'ll sort that part.

Help with getting member photos and pages into the editing process. My concern is keeping track of member contributions, also getting lost in and between Discord, Wiki etc . For me direct email is looking good as I can track member, time and tool in subject heading. But I get it about not wanting to share email addresses. I’m still very new at HS so cannot workout about gathering member help. Is a direct email, direct msg or other the best option? If anyone can suggest a best way of getting files into the editing process you have my greatest thanks.

Craig. I salute you. Thanks for great commitment, plan and vision for Metalworking.
